The FC 1400 is an antepartum fetalmonitor which detects and displays twin fetus heart s and uterine activity in rea the 7" col LCD monitor. Touch interface, along with eys for 16 functions, makes the operation easier and faster. Built-in printer provides easy-to-read printout for charting. Onboard memory allows ou to review and print up to 72 hours of internally stored sh drive interface provides a simple MR attachment. LAN a erface make it easy to adapt to wired vorking environments. Automatic fetal movement detection and TOCO zeroing reduces the CTG (Cardiotocography) interpretation provides the silent recommendation for NST (Non-Stress Test). The FC 1400 provides accurate and continuous obstetric measurements in themost rigorous clinical environments with a 3-yearwarranty.
Superior Data Display and Touch Interface
7" wide color LCD viewer (800x480 resolution).
Touch screen along with 10 smart keys for 16 functions.
Graphic and text display mode.
Yellow/green LED alarm lamp for easier recognition.
72 hour trace data reviewer.
Extreme Data Accuracy and Smart Function
Twin fetus heart rate and uterine activity.
More compact probes and robust connectors.
Automatic fetal movement detection.
Automatic TOCO zeroing.
Clinical mark and note entering.
CTG interpretation
Printout
Easy-to-read B4 size chart paper with folding line.
High-speed printout of stored data.
Paper feeding for short handwriting memo.
Enhanced Data Management
72-hour memory capacity.
USB flash drive storage for exporting JPG file to EMR.
Includes:
FC 1400 Main Unit, US Probe(x2), TOCO Probe, Event Marker Jack, Ultrasound Gel, Probe Belt (x3), Stand, Paper (x2), Power Adaptor & Hospital-Grade Power Cord, Operation Manual, and 3-Year Warranty Card.
Specification:
| Feature Specification |
| Dimension 296 (W) x 305.5 (H) x 97.5 (D) mm, approx. 2.6 kg |
| Display 7° TFT wide LCD screen (800 X 480) |
|
Recorder Method: Thermal array print |
| Power Input: 100-240 VAC, 1.5-0.7 A, 50-60 Hz/ Output: 18 VDC, 2.8A |
| Battery (option) Li-ion: 4 hours (charging) /2 hours (discharging) |
| External Link LAN, WiFi, USB flash drive |
| Fetal Heart Rate Input Signal: Ultrasound pulsed doppler Ultrasound frequency: 1.0 MHz, 975 KHz Ultrasound power: FHR detection method: Autocorrelation FHR range: 50~210 BPM FHR accuracy: 120~160: ±1 BPM /Except 120~160 BPM: +2 BPM |
| Uterine Contraction Input Source: External Transducer with load cell Reference Control: One touch switch, auto zeroing Measurement range: 0~99 |
| Fetal Movement Measurement Detection source: Ultrasound pulsed doppler, event marker |
| Data Storage Storage for 72 hours |
| Auto CTG Analysis Average Baseline FHR Number of UC Number of Acceleration Number of Deceleration: Late, Early, Variable High/Low Episode Short term Variability Signal Loss * CTG Analysis results is printed out every 10 minutes (Intermediate report) |
| Accessory (standard) Ultrasound doppler probe (2ea),UC probe (1ea), Event marker (1ea),Printer paper (2 rolls) Power adaptor & cord (1ea),Ultrasound gel (1ea),Probe belt (3ea),Operation manual (1ea), Stand (1ea) |
| Accessory(Option) Rechargeable battery (1ea),Cart, USB WiFi Dongle |
